POWERED SCAFFOLDING > SWING STAGE > Platform

Modular Platform
w/End Stirrups

Modular Platform
w/Walk-Through Stirrups

Modular aluminum platforms are a lightwight, easy-to-assemble, and versatile access solution with many options.

Modular Platform Accessories

Work Cage, Bosun's Chair & Boiler Stage

Hinges, corner sections, and stirrups allow platform to conform to any shape!

Use work cages & bosun chairs for access in confined spaces.






























MODULAR PLATFORM WITH END STIRRUPS

Total Length (ft) Cantilever Length (ft) Max. Span Distance Between Hoists (ft) Platform Configuration* (ft) Rated Working Load (lbs)** Total Platfofm Weight (lbs)
6 NONE 6 6 2000 160
10 NONE 10 10 2000 200
13 NONE 13 6-6 2000 271
16 NONE 16 10-6 2000 310
20 NONE 20 10-10 2000 348
23 NONE 23 6-10-6 1500 420
26 NONE 26 10-6-10 1500 458
30 NONE 30 10-10-10 1000 446
33 NONE 33 10-6-6-10 1000 568
36 NONE 36 10-10-10-6 1000 607
40 NONE 40 10-10-10-10 1000 645
43 NONE 43 10-10-6-6-10 750 717
46 NONE

46

 10-10-6-10-10 750 755
49 NONE 49 10-10-10-10-10 750 830
F676C NONE - -   60 lb

*

** Altrex platform capacities at maximum distance between hoists.


Top

































MODULAR PLATFORM WITH WALK-THROUGH STIRRUPS

Total Length (ft) Cantilever Length (ft) Max. Span Distance Between Hoists (ft) Platform Configuration* (ft) Rated Working Load (lbs)** Total Platfofm Weight (lbs)
30 3 23  3  - 6-10-6 -  3  750 847
33 3 26  3  - 10-6-10 -  3  1000 884
36 3 30  3  - 10-10-10 -  3  1000 924
40 3 33  3  - 10-6-6-10 -  3  1000 994
43 3 36  3  - 10-10-10-6 -  3  1000 1034
46 3 40  3  - 10-10-10-10 -  3  100 1071
49 3 43  3  - 10-10-6-6-10 -  3  750 1144
52 3 46  3  - 10-10-6-10-10 -  3  750 1181
55 3 49  3  - 10-10-10-10-10 -  6  750 1221
46 6 33  6  - 10-6-6-10 -  6  750 1056
49 6 36  6  - 10-10-10-6 -  6  750 1096
52 6 40  6  - 10-10-10-10 -  6  750 1133
55 6 43  6  - 10-10-6-6-10 -  6  750 1206
59 6 46  6  - 10-10-6-10-10 -  6  750 1243
62 6 49  6  - 10-10-10-10-10 -  6  750 1283

*

** Altrex platform capacities at maximum distance between hoists.


Top

































MODULAR PLATFORM ACCESSORIES

Platform Hinge Section Fixed Corner Sections
Required when more than two stirrups support a straight platform.  Can be used to extend a platform beyond the standard configuration. Available in 30�, 45�, 60�, & 90� (shown) sections.  Requires U-frames on each platform end.
Adjustable Corner Section Walk-Thru Stirrup

Adds greatest flexibility to the corner section.   Adjustable to 20�, 30�, 45�, 51�, 60�, 72�, & 90� for easier platform assembly and rigging.

Can be positioned at any location along the platform for proper rigging.  Used with end guardrails when using cantilever sections.
Description Measurement
(Length X Width X Height)		 Overall Length Weight
PLATFORM HINGE SECTION 19" L X 28" W X 21" H -- 11 lb
30� CORNER SECTION 11" L X 27.5" W X 43" H 20" 21 lb
45� CORNER SECTION 15" L X 27.5" W X 43" H 26" 23 lb
60� CORNER SECTION 16" L X 27.5" W X 43" H 29" 30 lb
90� CORNER SECTION 43" L X 27.5" W X 43" H 60" 64 lb
ADJUSTABLE CORNER SECTION Variable Variable 128 lb
STEEL WALK-THRU STIRRUP 39-1/4" L X 27-1/8" W X 87" H -- 135 lb
ALUMINUM WALK-THRU STIRRUP 38" L X 24" W X 90" H -- 105 lb



Top































WORK CAGE, BOSUN CHAIR, AND BOILER STAGE

Low Profile Knock Down Work Cage Work Cage
Compact cage for easy overhead work for one or two men.  Can be broken down to fit through an entrance of 18" diameter. For narrow working conditions.  Single walk-thru stirrup allows construction of continuous runs or work cages of various sizes.


Boiler Stage Bosun's Chairs

 Designed for enclosed spaces where access entrance size is no less than 18" in diameter with a maximal wall thickness of 7".

 Fast and reliable work platform for inspection and maintenance outdoors or inside very narrow structures such as furnaces, wells, and tanks.
Description Measurement Maximum Rated Working Load Weight
LOW PROFILE KNOCK DOWN
WORK CAGE		 -- 1000 lb 102 lb
WORK CAGE - 1M 3'9" L X 28" 330 lb 200 lb
WORK CAGE - 2M 6'9" L X 28" 660 lb 230 lb
BOSUN CHAIR -- -- --
BOILER STAGE -  3 M PLATFORM 9'9" L 750 lb 420 lb
BOILER STAGE -  4 M PLATFORM 13'6" L 750 lb 500 lb
BOILER STAGE - 5 M PLATFORM 16'6" L 750 lb 580 lb
BOILER STAGE -  6 M PLATFORM 19'6" L 1650 lb 590 lb
BOILER STAGE -  7 M PLATFORM 23'3" L 1650 lb 670 lb
BOILER STAGE -  8 M PLATFORM 26'3" L 1650 lb 750 lb
BOILER STAGE -  9 M PLATFORM 29'3" L 1150 lb 760 lb
BOILER STAGE -  10 M PLATFORM 33' L 1150 lb 870 lb
BOILER STAGE -  11 M PLATFORM 36' L 1150 lb 910 lb
BOILER STAGE -  12 M PLATFORM 39' L 750 lb 920 lb
BOILER STAGE -  13 M PLATFORM 42'9" L 750 lb 1000 lb
BOILER STAGE -  14 M PLATFORM 45'9" L 750 lb 1080 lb

Rated working loads must be evenly distributed on platform.

Maximum Load On Boiler Stage Cantilever = 275 lb.
Maximum Cantilever Length = 3 ft.
